RFL Electronics RFL 9300 - Table 21-1. Replaceable Parts, RFL 93 Alarm I;O Module

Table 21-1. Replaceable parts, RFL 93 Alarm I/O Module.
Assembly No. 104775-5
Circuit Symbol
(Figs. 21-3 & 21-4)
Description Part Number
CAPACITORS
C1-6 Capacitor, ceramic disc, 0.005μF, 20%, 3kV 1007 1264
C7, 8, 19-22 Capacitor, ceramic disc, 0.005μF, 20%, 3kV 1007 1264
C10 Capacitor, tantalum, 1μF, 20%, 35V 1007 496
C12, 14, 17, 18 Capacitor, ceramic, 0.1μF, 10%, 50V 0130 51041
C13 Capacitor, tantalum, 33μF, 10%, 10V, axial 1007 1142
C15, 16 Capacitor, electrolytic, 47μF, 20%, 35V 1007 1578
C23, 24 Capacitor, ceramic dip, 0.01μF, 5%, 100V 1007 1645
RESISTORS
R1, 2, 4, 8, 11 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R5 Resistor, metal film, axial, 2.61K, 1%, 1/4W 0410 1328
R6, 7 Resistor, metal film, axial, 3.16K, 1%, 1/4W 0410 1336
R10 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
R18 Resistor, metal film, axial, 619Ω, 1%, 1/4W 0410 1268
R20, 22 Resistor, metal film, axial, 3.01K, 1%, 1/4W 0410 1334
R21, 23 Resistor, metal film, axial, 5.9K, 1%, 1/4W 0410 1362
R24, 30 Resistor, metal film, 43K, 2%, 2W 1510 2374
R25, 31 Resistor, metal film, 27K, 2%, 2W 1510 2373
R26, 32 Resistor, wirewound, 5K, 5%, 3.25W 1100 460
R27 Resistor, metal film, axial, 332Ω, 1%, 1/4W 0410 1242
R28, 29 Resistor, wirewound, 25K, 5%, 3W 1100 833
R33 Resistor, metal film, axial, 31.6K, 1%, 1/4W 0410 1432
R34, 35 Resistor, metal film, axial, 12.1K, 1%, 1/4W 0410 1392
SEMICONDUCTORS
CR1, 4 Diode, silicon, 1N914B/1N4448 26482
CR2, 3 Diode, silicon, rectifier, 1Amp, 1N4003 30769
CR7 Rectifier, avalanch, 600V, 1A, 1N4005 26935
CR8 Suppressor, transient voltage, 1.5KE350CA 101722
CR9, CR11 Diode, Zener, 20V, 5%, 1W, 1N4747A 20794
CR10, 12 Diode, silicon, rectifier, 1Amp, 1N4003 30769
Q1-3 Transistor, NPN, 40V, 2N4401 42574
Q4 Transistor, silicon, NPN, 700V, 5A 102870
Q5, 6 Transistor, silicon, PNP, 2N3906 21565
U1 Integrated Circuit, MOS, tri-state buffer 0615 290
U2 Switch, solid state 102842
U3, 4 Opto device, iso-coupler, MOC8021 90271
MISCELLANEOUS COMPONENTS
J1-6 Connector, header, single, 2 ckt 32802 2
K4, 5 Relay, SPDT, 12V, PCB, sealed 101236
L1 Inductor, 10μH, 5%, 1.5A max 30285
L2-12 Inductor, 10μH, 5%, 1.5A max 102698
TB8, 9 Terminal block, 6 terminal 101233
