18.2 DESCRIPTION
Table 18-1 summarizes the differences between the various single width fiber optic I/O modules. A more de-
tailed description of these modules can be found below.
Table 18-1. Differences between Single Width Fiber Optic I/O Modules
Model
Number
Assembly
Number
Type Wavelength/Mode Connector Peak
Light
Level *
Average
Light
Level *
RFL 93FT/FR I/O-8M 105850 LED Emitter/Detector 850-nm Multimode ST -10dBm -13dBm
RFL 93FT/FR I/O-13M 105855 LED Emitter/Detector 1300-nm Multimode ST -10dBm -13dBm
RFL 93FT/FR I/O-13S 105860 LED Emitter/Detector 1300-nm Singlemode ST -14dBm -17dBm
RFL 93FT/FR I/O-13SL 105865 LASER Emitter/Detector 1300-nm Singlemode ST +3dBm 0dBm
RFL 93FT/FR I/O-15SL 105870 LASER Emitter/Detector 1550-nm Singlemode ST +2dBm -3dBm
* Light levels are emitter outputs for fiber optic I/O modules, and detector inputs for fiber optic I/O modules.
18.3 SPECIFICATIONS
As of the date this manual was published, the following specifications apply to all RFL 9300 single width fiber
optic I/O modules, except where indicated. Because all RFL products undergo constant refinement and im-
provement, these specifications are subject to change without notice.
Input Power Requirements (from chassis supply):
RFL 93 FT/FR I/O-8M:
+5-Volt Supply: 120 mA
+15-Volt Supply: 80 mA
-15-Volt Supply: 80 mA
RFL 93 FT/FR I/O-13M and RFL 93 FT/FR I/O-13S:
+5-Volt Supply: 130 mA
+15-Volt Supply: 50 mA
-15-Volt Supply: 20 mA
RFL 93 FT/FR I/O-13SL and RFL 93 FT/FR I/O-15SL:
+5-Volt Supply: 6 mA
+15-Volt Supply: 50 mA
-15-Volt Supply: 80 mA
Input Drive Signals: TTL logic-level, generated by RFL 93B FT/FR single width fiber optic transceiver module
(Section 17).
Output Light Signal Characteristics: See Table 18-1.
Temperature:
Storage: -40
O
C to +75
O
C (-40
O
F to +167
O
F).
Operating: -30
O
C to +65
O
C (-22
O
F to +149
O
F).
Relative Humidity: 95 percent, non-condensing.
Dimensions:
Width (including panel) 1.4 inches (3.6 cm)
Height (including panel) 5 inches (12.7 cm)
Depth (behind panel) 4.7 inches (12.0 cm)
