RFL 9300 RFL Electronics Inc.
August 9, 2001 9 - 13 (973) 334-3100
Table 9-3. Replaceable parts for oscillography board, used in RFL 9300 display modules (Assembly No. 106330)
Circuit Symbol
(Figs. 9-5 & 9-7)
Description Part Number
CAPACITORS
C101 Capacitor, tantalum, 33μF, 10%, 10V 1007 1142
C102, 103 Capacitor, electrolytic, 47μF, 20%, 25V 1007 1578
C104-106, 110, 113- Capacitor, ceramic, 0.1μF, GMV, 50V 1007 1366
118, 131-149
C107-109, 123-126 Capacitor, ceramic dipped, 0.01μF, 5%, 100V 1007 1645
C111 Capacitor, tantalum, 3.3μF, 20%, 35V 1007 1260
C112, 128, 129 Capacitor, electrolytic, 47μF, 20%, 16V 1007 1629
C119 Capacitor, polystyrene, .0039μF, 2%, 10V 5115 15
C120, 121 Capacitor, ceramic, 33pF, 10%, 200V 0125 23301
C122 Capacitor, ceramic, 120pF, 5%, 200V 0125 21215
C127 Capacitor, tantalum, .33μF, 10%, 35V 1007 1281
C130 Capacitor, tantalum, 4.7μF, 20%, 20V 1007 711
RESISTORS
R101 Resistor, metal film, precision, 5.9KΩ, 1%, 1/4W 0410 1362
R102 Resistor, metal film, precision, 3.01KΩ, 1%, 1/4W 0410 1334
R103 Resistor, metal film, precision , 9.76KΩ,1%, 1/4W 0410 1383
R104 Resistor, metal film, precision , 3.16KΩ, 1%, 1/4W 0410 1336
R105, 127, 154, 155 Resistor, metal film, precision , 1KΩ, 1%, 1/4W 0410 1288
R106 Resistor, metal film, precision , 24.9KΩ, 1%, 1/4W 0410 1422
R107 Resistor, metal film, precision , 49.9KΩ, 1%, 1/4W 0410 1451
R108 Resistor, metal film, precision, 7.15KΩ, 1%, 1/4W 0410 1370
R120, 126, 132, 135- Resistor, metal film, precision, 4.99KΩ, 1%, 1/4W 0410 1355
138, 143-146
R121, 122 Resistor, metal film, precision, 909Ω, 1%, 1/4W 0410 2284
R123, 124, 134, Resistor, metal film, precision, 10KΩ, 1%, 1/4W 0410 1384
151-153
R125 Resistor, metal film, precision, 20KΩ, 1%, 1/4W 0410 1413
R128 Resistor, metal film, precision, 1432Ω, 1%, 1/4W 0410 2253
R129 Resistor, metal film, precision, 8.25KΩ, 1%, 1/4W 0410 1376
R130 Resistor, metal film, precision, 237KΩ, 1%, 1/4W 0410 1516
R131 Resistor, metal film, precision, 2.0 MegΩ, 1%, 1/4W 0410 1605
R133
Resistor, metal film, precision, 4.02KΩ, 1%, 1/4W 0410 1346
