RFL Electronics RFL 9300 - Table 20-2. Replaceable Parts, RFL 93 Relay I;O Module, Current Sense Board

Table 20-2. Replaceable parts, RFL 93 Relay I/O module, Current Sense board
(Assembly No. 106388-2)
Circuit Symbol
(Figs. 20-5 & 20-7)
Description Part Number
CAPACITORS
C201-204 Capacitor,ceramic,0.1μF,10%,50V 0120 38
C205 Capacitor,tantalum,10μF,20%,25V 1007 1563
C206,208,210 Capacitor,ceramic,0.1μF,10%,100V 0130 11041
C207 Capacitor,electrolytic,200μF,-10+75%,25V 1007 900
C209 Capacitor,electrolytic,47μF,20%,35V 1007 1578
RESISTORS
R201-208 Resistor,metal film,axial,5.11KΩ,1%,1/4W 0410 1356
R209,218 Resistor,metal film,axial,10K,1%,1/4W 0410 1384
R210,211,212,213 Resistor,metal film,axial,69.8Ω,1%,1/4W 0410 1177
R214 Resistor,metal film,axial,6.81K,1%,1/4W 0410 1368
R215 Resistor,metal film,axial,3.16K,1%,1/4W 0410 1336
R216 Resistor,metal film,axial,3.01K,1%,1/4W 0410 1334
R217,219 Resistor,metal film,axial,5.11K,1%,1/4W 0410 1362
R220 Resistor,metal film,axial,1K,1%,1/4W 0410 1288
RZ201 Resistor network,10K,9R/PKG,SIP 32200
SEMICONDUCTORS
CR201,203,204 Diode,silicon,rectifier,1 Amp,1N4003 30769
Q201 Transistor,silicon,PNP,2N3906 21565
Q202 Transistor,NPN,40V,2N4401 42574
U201 Integrated circuit,MOS,Hex inverter,Schmitt trigger 0615 242
U202 Integrated circuit,MOS,QUAD 2-input NAND gate 0615 159
U203 Integrated circuit,MOS,Octal D-latch 0615 308
U204 Transistor array,ULN2803A 0720 7
U205,206,207 Opto device,photo,ISO,4N35 47104
MISCELLANEOUS COMPONENTS
K201 Relay,SPDT,12V,PCB,sealed 101236
K203,204,205,206 Relay,SPDT,12VDC,37.5MA,SPCL 102860
L1 Inductor,axial,47μH,15%,1.6A 105411
P201 Connector,plug,female,64cont,DIN 99134
P202 Connector, wafer assembly,12 CKT 42082 12
P203
Connector, JK male,16P,vertical
30202
RFL 9300 RFL Electronics Inc.
May 5, 2002 20 - 9 (973) 334-3100
