Table 6-5. READ mode parameters for RFL 9300 Two-Terminal Charge Comparison Systems
No. Display Definition
... Moving dots RFL 9300 is in STANDBY mode. Display controller parameter; not user-selectable.
0 EXIT Exit to STANDBY mode. Display function; can be set to either ENABLE or DISABLE. (1)
1 PngPng 1 Value of ping-pong (round-trip delay) for remote 1.
3 CDC 1 One-way Rx delay for remote 1.
5 LOC IA Local Phase A current.
6 LOC IB Local Phase B current.
7 LOC IC Local Phase C current.
8 LOC 3I0 Local 3I0 current.
9 REM1 IA Remote 1 Phase A current.
10 REM1 IB Remote 1 Phase B current.
11 REM1 IC Remote 1 Phase C current.
12 REM1 3I0 Remote 1 3I0 current.
17 RCV ADD1 Remote 1 Rx address. (2)
19 ALARMS Present alarm status (four alarms).
20 PH BIAS Phase bias. Programmable; see table 6-9 for more information.
21 GND BIAS Ground bias. Programmable; see table 6-9 for more information.
22 BIAS CTL Bias control. Programmable; see table 6-9 for more information.
23 GND DLY Enable/disable ground delay. Programmable; see table 6-9 for more information.
24 DLAY SEC Bias control and ground delay time (in seconds). Programmable; see table 6-9 for more information.
25 FD PHASE Local phase fault detector current. Programmable; see table 6-9 for more information.
26 FD GND Local ground fault detector current. Programmable; see table 6-9 for more information.
27 BACKUP System backup functions. Programmable; see table 6-9 for more information.
28 PH OC BU Phase overcurrent backup. Programmable; see table 6-9 for more information.
29 G OC BU Ground overcurrent backup. Programmable; see table 6-9 for more information.
30 PH TOC Local phase time-overcurrent backup. Programmable; see table 6-9 for more information.
31 P PICKUP Local phase time-overcurrent pickup value. Programmable; see table 6-9 for more information.
32 PH CURVE Local phase time-overcurrent curve select value. Programmable; see table 6-9 for more information.
33 PH DIAL Local phase time-overcurrent dial setting value. Programmable; see table 6-9 for more information.
34 GND TOC Local ground time-overcurrent backup. Programmable; see table 6-9 for more information.
35 G PICKUP Local ground time-overcurrent pickup value. Programmable; see table 6-9 for more information.
36 G CURVE Local ground time-overcurrent curve select value. Programmable; see table 6-9 for more information.
37 GND DIAL Local ground time-overcurrent dial setting value. Programmable; see table 6-9 for more information.
38 OVHD/UGD Overhead or underground cable. Programmable; see table 6-9 for more information.
39 OPEN CON Open conductor action. Programmable; see table 6-9 for more information. (7)
40 STUB BUS Stub bus active/inactive.
41 CM ALM D Communications alarm delay. Programmable; see table 6-9 for more information.
42 DC FILT Enable/disable dc filter. Programmable; see table 6-9 for more information.
43 DEFAULT Re-program to factory default values. Programmable; see table 6-9 for more information. (4)
44 BEEPER Enable/disable audible beeper. Programmable; see table 6-9 for more information. (5)
45 DISPLAY Adjust display intensity. Programmable; see table 6-9 for more information. (6)
46 XMT ADD1 Transmit address to remote 1. Programmable; see table 6-9 for more information.
48 COM MODE Selects hot standby communications mode. Programmable; see table 6-9 for more information.
>> Table continues on next page <<
>> Refer to page 6-24 for notes <<
