RFL 9300 RFL Electronics Inc.
January 30, 2002 6-20 (973) 334-3100
Table 6-5 continued. READ mode parameters for RFL 9300 Two-Terminal Charge Comparison Systems
49 ACT CHAN Selects channel for hot standby communications. Programmable; see table 6-9 for more information.
50 G B4 TRP Enable/disable guard before trip. Programmable; see table 6-9 for more information.
51 RS232 BD Selects RS-232 baud rate. Programmable; see table 6-9 for more information.
52 RS232PR Selects RS-232 handshaking protocol. Programmable; see table 6-9 for more information.
53 R1 PH BS Remote 1 phase bias.
54 R1 GD BS Remote 1 ground bias.
55 R1 BS CL Remote 1 bias control.
56 R1 GD DY Remote 1 ground delay action.
57 R1 DLY S Remote 1 time delay.
58 R1 FD PH Remote 1 fault detector phase current.
59 R1 FD GD Remote 1 fault detector ground current.
60 R1 BCKUP Remote 1 backup functions.
61 R1 PH OC Remote 1 phase overcurrent backup.
62 R1 GD OC Remote 1 ground overcurrent backup.
63 R1 P TOC Remote 1 phase inverse time-overcurrent backup.
64 R1 PPKUP Remote 1 phase inverse time-overcurrent pickup value.
65 R1 PCURV Remote 1 phase inverse time-overcurrent curve select value.
66 R1 PDIAL Remote 1 phase inverse time-overcurrent dial setting value.
67 R1 G TOC Remote 1 ground inverse time-overcurrent backup.
68 R1 GPKUP Remote 1 ground inverse time-overcurrent pickup value.
69 R1 GCURV Remote 1 ground inverse time-overcurrent curve select value.
70 R1 GDIAL Remote 1 ground inverse time-overcurrent dial setting value.
71 R1 OH/UG Remote 1 overhead or underground.
72 R1 OP/CN Remote 1 open conductor action. (7)
73 R1 STUB Remote 1 stub bus action.
74 R1 DCFIL Remote 1 dc filter.
75 R1 GD TP Remote 1 guard before trip.
76 R1 PNGPG Remote 1 ping-pong (round-trip delay).
77 R1 CDC Remote 1 channel delay compensation.
103 SWID CC1 Software version number for local communications controller in two-terminal systems.
104 SWID CC2 Software version number for second local communications controller in three-terminal systems.
105 SWID SV Software version number for local supervisor module.
106 SWID PCA Software version number for local Phase Controller "A" module.
107 SWID PCB Software version number for local Phase Controller "B" module.
108 SWID PCC Software version number for local Phase Controller "C" module.
109 SWID PCG Software version number for local Phase Controller "G" module.
110 SWID DC Software version number for local display module.
111 EXIT Exit to STANDBY mode. Same as parameter #0. (1)
140 SGL POLE Single-Pole trip – active/inactive
141 SEL POLE Enable/Disable Selective pole relaying – Programmable; see table 6-9 for more information (8)
145 TRIP RLS Trip release codes – Programmable; see table 6-9 for more information
160 RS1 POLE Remote 1 single-pole trip – active/inactive
161 R1 SEL P Remote 1 Selective pole relaying
165 TRP RLS 1 Remote 1 Trip release codes
>> Refer to page 6-24 for notes <<
