RFL 9300 RFL Electronics Inc.

August 9, 2001 9 - 16 (973) 334-3100

Table 9-4. Replaceable parts for front panel assembly, used in RFL 9300 display module (Assembly No. 106335)

Circuit Symbol

(Figs. 9-6 & 9-7)

Description Part Number

CAPACITORS

C201-205

Capacitor, ceramic, 0.1μF, 10%, 50V

0130 51041

C206-208

Capacitor, tantalum, 33μF, 10%, 10V

1007 1142

RESISTORS

R201 Resistor, metal film, precision, 2.21K, 1%, 1/4W 0410 1321

RZ201 Resistor network, 2.2K, 9R/PKG, SIP 103897

SEMICONDUCTORS

U201, 204 IC, MOS, Octal, 3st, Noninverting, BFR/LD 0615 297

U202, 203 Display, alphanumeric, 8-digit 101285

U205 IC, MOS, 2 to 4 line decoder, multiplexer 0615 269

U206 Transistor array, MPQ 2222 49478

MISCELLANEOUS COMPONENTS

J202 Jumper connector, programmable 98306

KP201 Keypad, 12-button (3 x 4), Post Mtg. 101232
