The DC RESTORE signal is normally held high for steady-state power system currents. During disturbances
that contain a dc component, the phase controller module drops DC RESTORE low. This closes section D of
analog switch U4 and shorts out capacitor C3. Since the circuit is basically operating open-loop, there must be
some form of dc stability around the overall loop. The output of the current-to-voltage converter is fed back
through a voltage divider formed from resistors R28 and R29. Resistor R24 and capacitor C3 form a low pass
filter. This filter strips out the ac component, and provides dc feedback to sense amplifier U1.
During disturbances with a dc component, the phase controller module modulates the DC RESTORE line. This
allows reproduction of the transient without charging C3 to a false dc level that could saturate sense amplifier
U1.
Table 11-1. Replaceable parts, RFL 93B ACT-5 5-Ampere Auxiliary Current Transformer to I/O Module
(Assembly No. 106345-5)
Circuit Symbol
(Figs. 11-4 & 11-5)
Description Part Number
CAPACITORS
C1,2
Capacitor,tantalum,4.7μF,20%,20V,Kemet T322B475M020AS or equiv.
1007 711
C3,7
Capacitor,metallized polycarbonate,0.22μF,2%,50V,Wesco 32MPC or equiv.
1007 1329
C4
Capacitor,X7R ceramic,0.001μF,10%,100V,AVX SA101C102KAA or equiv.
0130 11021
C5,6
Capacitor,tantalum,1μF,10%,35V,Kemet T110A105K035AS or equiv.
1007 1156
C8
Capacitor,ceramic,0.01μF,5%,100V,AVX SR301A103JAA or equiv.
1007 1645
C9
Capacitor,ceramic,0.001μF,5%,100V,AVX SA201A102JAA or equiv.
0125 11025
C10-19
Capacitor,ceramic,0.1μF,GMV,50V,Centralab CY20C104P or equiv.
1007 1366
C20 Capacitor,ceramic,10pF,10%,100V,AVX SA101A100KAA or equiv. 0125 11001
RESISTORS
R1,9 Resistor,metal film,1K,1%,1/4W, Type RN1/4 0410 1288
R2,4,10,12 Resistor,metal film,4.75K,1%,1/4W, Type RN1/4 0410 1353
R3,11 Resistor,metal film,39.2K,1%,1/4W, Type RN1/4 0410 1441
R5,6,13,14
Resistor,metal film,221Ω,1%,1/4W, Type RN1/4
0410 1225
R7,8,15,16
Resistor,metal film,10Ω,1%,1/8W,Type RN55D
1510 1092
R17 Resistor,metal film,649K,0.1%,0.2W,200V maximum working voltage, 1510 2274
Dale CMF-55-6490BT9 or equiv.
R18 Resistor,metal film,factory-selected value Contact factory
R19,20 Resistor,metal film,1.62K,1%,1/4W, Type RN1/4 0410 1308
R21 Resistor,metal film,2.32K,1%,1/4W, Type RN1/4 0410 1323
R22 Resistor,metal film,10K,1%,1/4W, Type RN1/4 0410 1384
R23 Resistor,metal film,100K,1%,1/4W, Type RN1/4 0410 1480
R24 Resistor,metal film,301K,1%,1/4W, Type RN1/4 0410 1526
R25,26 Resistor,metal film,4.99K,1%,1/4W, Type RN1/4 0410 1355
R27 Resistor,metal film,113K,1%,1/4W, Type RN1/4 0410 1485
