Table 18-3 (continued). Replaceable parts, Singlewidth fiber optic I/O modules
RFL 93 FT/FR I/O-13M (Singlemode) (Assembly No. 105855)
RFL 93 FT/FR I/O-13S (Multimode) (Assembly No. 105860)
Circuit symbol
(Figs 18-10 & 18-11)
Description Part number
RESISTORS (continued)
R28 Resistor, metal film, precision, 150K, 1%, 1/4W 0410 1497
R30, 32
Resistor, metal film, precision, 301Ω, 1%, 1/4W
0410 1238
R31 Resistor, metal film, precision, 14.7K, 1%, 1/4W 0410 1400
R33 Resistor, metal film, precision, 60.4K, 1%, 1/4W 0410 1459
R34, 42, 44 Resistor, metal film, precision, 10K, 1%, 1/4W 0410 1384
R36, 37, 39, 40
Resistor, metal film, precision, 475Ω, 1%, 1/4W
0410 1257
R45 Resistor, metal film, precision, 4.32K, 1%, 1/4W 0410 1349
SEMICONDUCTORS
CR6 Opto device, fiber optic detector, 1300/1550-nm 101733
Q2 Transistor, VMOS, FET, VN10KM 0715 13
U1 Opto device, fiber optic emitter, 1300nm
For multimode module (Assembly No. 105855) 101731
For singlemode module (Assembly No. 105860) 101727
U3 IC, linear, dual comparator 0620 319
U4, 7 IC, linear, JFET, OP AMP 0620 227
U5 IC, low noise, video OP AMP 0620 354
U6 IC, analog switch, quad, SPST, CMOS 0605 17
U8, 9 IC, linear, IF amplifier 0620 251
U10 IC, MOS, hex inverter, unbufferd 0615 304
MISCELLANEOUS COMPONENTS
L1, 2
Inductor, molded, 33 μH, 130MA
32868
L3, 4, 5, 6
Inductor, molded, RF, 100 μH, 10%
32505 1
P1 Connector, plug, female, 64 contact, DIN 99134
TP1-4 Test point, terminal, orange 98441 3
RFL 9300 RFL Electronics Inc.
January 19, 2005 18 - 18 (973) 334-3100
