NOTE
THIS STARTUP MODE PROCEDURE SHOULD BE RUN AT EACH STATION TO INSURE
PROPER INSTALLATION. PASSING THE PROCEDURE AT ONE STATION ONLY WILL NOT
VERIFY THE WIRING ADEQUATELY. THE PHASE A SHUNT TEST PORTION OF THE PHASE
SEQUENCE TEST SHOULD BE RUN AT EACH STATION.
To assist in trouble shooting any wiring problem without exiting the STARTUP Mode, the following parameters
are active and may be displayed.
The display shows the parameter number for each measured value and a brief description of its meaning.
001 - Ping Pong R1 Ping-pong delay for remote 1. Equal to one-half the round-trip delay.
002 - Ping Pong R2 Ping-pong delay for remote 2. Equal to 1/2 the round-trip delay. (3 terminal only)
003 - Sequence Test Phase Sequence Test.
004 - Diff Cur Test Differential Current Test.
005 - Local I A Local Phase A current.
006 - Local I B Local Phase B current.
007 - Local I C Local Phase C current.
008 - Local 3I0 Local 3I
0
current.
009 - Remote #1 I A Remote #1 Phase A current.
013 - Remote #2 I A Remote #2 Phase A current. (3 terminal only)
RFL 9300 RFL Electronics Inc.
October 20, 2004 8 - 37 (973) 334-3100
