RFL 9300 RFL Electronics Inc.
August 9, 2001 9 - 10 (973) 334-3100
Table 9-2. Replaceable parts for display controller board, used in RFL 9300 display module. (Assembly No.
106325-2)
Circuit Symbol
(Figs. 9-4 & 9-7)
Description Part Number
CAPACITORS
C301-324, 329 Capacitor, ceramic, 0.01μF, GMV, 50V 1007 1366
C325, 326 Capacitor, ceramic, 22pF, 5%, 200V 0125 22205
C327, 328 Capacitor, tantalum, 33μF, 10%, 10V 1007 1142
RESISTORS
R301, 302, 307- Resistor, metal film, precision, 10K, 1%,1/4W 0410 1384
310, 312-314,
323
R303, 304, 311, Resistor, metal film, precision, 1K, 1%, 1/4W 0410 1288
319-321
R316, 322 Resistor, metal film, precision, 221Ω, 1%, 1/4W 0410 1225
R317 Resistor, metal film, precision, 1.62K, 1%, 1/4W 0410 1308
R318 Resistor, metal film, precision, 845Ω, 1%, 1/4W 0410 1281
RZ301, 304 Resistor network, 10K, 5R/PKG, SIP 32664
RZ302, 303, 305, Resistor network, 10K, 9R/PKG, SIP 32622
307
RZ306 Resistor network, 221Ω, 9R/PKG, SIP 30165
SEMICONDUCTORS
DS301 Opto device, LED, bi-color, red-green 102801
DS302 Opto device, LED 30162
DS303-305 Opto device, LED, red 99294
Q301 Transistor, silicon, PNP,2N3906 21565
U301 IC, MOS, quad buffer/line driver 0615 292
U302 IC, MOS, quad 2-input NOR gate 0615 160
U303 IC, interface transceiver, RS-485 0680 14
U304 IC, MOS, tri-state octal buffer 0615 176
U305 IC, MOS, PEEL, 25NS 0615 365
U306 IC, MOS, Dual D-flip flop 0615 166
U307, 319 IC, MOS, Hex inverter, Schmitt trigger 0615 242
U308 IC, Peripheral, Microprocessor supervisor 0635 27
U309 IC, CHMOS, Microcontroller 0615 459
>> table continues on next page <<
