RFL Electronics RFL 9300 - Page 289

RFL 9300 RFL Electronics Inc.
October 29, 2001 10 - 10 (973) 334-3100
Table 10-1. Replaceable parts, supervisor controller module for RFL 9300
RFL 93B SV (Assembly No. 106300-1)
Circuit Symbol
(Figs. 10-3 & 10-4)
Description Part Number
CAPACITORS
C1-7,9-20,23-30,35,39,40
Capacitor,ceramic dip,0.1μF,10%,50V
0120 38
C31,32,43
Capacitor,ceramic dip,0.01μF,5%,100V,AVX
SR301A103JAA or equiv.
1007 1645
C33,34 Capacitor,ceramic,22pF,5%,200V
0125 22205
C36
Capacitor,tantalum,33μF,10%,10V
1007 1142
C37,38
Capacitor,ceramic,0.001μF,5%,100V
0125 11025
C41,42
Capacitor,electrolytic,47μF,20%
1007 1578
RESISTORS
R1-4,14 Resistor,metal film axial,1K,1%,1/4W,Type RN1/4
0410 1288
R5,6
Resistor,metal film axial,221Ω,1%,1/4W,Type RN1/4
0410 1225
R7,8,11-13,16,17,18 Resistor,metal film axial,10K,1%,1/4W,Type RN1/4
0410 1384
R9 Resistor,metal film axial,5.62K,1%,1/4W,Type RN1/4
0410 1360
R10 Resistor,metal film axial,154K,1%,1/4W,Type RN1/4
0410 1498
R15 Resistor,metal film axial,46.4K,1%,1/4W,Type RN1/4
0410 1448
R19-21 Resistor,metal film axial,1.24K,1%,1/4W,Type RN1/4
0410 1297
R22 Resistor,metal film axial,6.19K,1%,1/4W,Type RN1/4
0410 1364
R23 Resistor,metal film axial,2.49K,1%,1/4W,Type RN1/4
0410 1326
R24 Resistor,metal film axial,15K,1%,1/4W,Type RN1/4
0410 1401
R25 Resistor,metal film axial,1.5K,1%,1/4W,Type RN1/4
0410 1305
R26 Resistor,metal film axial,1.06K,1%,1/4W, Type RN1/4
0410 1375
RZ1,8 Resistor network,seven 10K,2% resistors,1.1W total,8-pin
SIP, CTS of Berne 750-81-R10K or equiv.
47878
RZ2-7,9 Resistor network,nine 10K,2% resistors,1.25W total,10-pin
SIP, Bourns 4310R-101-103 or equiv
32622
<< table continues on next page>>
