Table 12-1 continued. Replaceable parts, phase controller modules for RFL 9300 Charge Comparison System
Circuit Symbol
(Figs. 12-3 & 12-4)
Description Part Number
RESISTORS - continued.
R24,25 Resistor,metal film,221W,1%,1/4W, Type RN1/4 0410 1225
R28 Resistor,metal film,100W,1%,1/4W, Type RN1/4 0410 1192
RZ1-6 Resistor network,nine 10KW 2% resistors,1.25W total,10-pin SIP,Bourns 4310R-101-103 or equiv. 32622
RZ7 Resistor network,nine 47KW 2% resistors,2.7W total,10-pin SIP,TRW/IRC 810-1-473G or equiv. 49511
SEMICONDUCTORS
CR1-3 Diode,silicon,1N914B or 1N4448 26482
DS1,2 Light-emitting diode,red,right-angle PC mount,extended length,Industrial Devices 5300H1 or equiv. 99294
U1 MOS tri-state octal buffer,inverting,20-pin DIP,National Semiconductor MM74HC240N or equiv. 0615 182
U2 MOS hex inverter,14-pin DIP,Motorola MC74HC05N or equiv. 0615 371
U3 MOS quad buffer/line driver,14-pin DIP,Signetics 74HC125N or equiv. 0615 292
U4 MOS multiplexer,8-input,tri-state outputs,16-pin DIP,Motorola MC74HC251N or equiv. 0615 372
U5 MOS tri-state buffer,16-pin DIP,National Semiconductor MM74HC367N or equiv. 0615 290
U6 MOS triple 3-input NAND gate,14-pin DIP,National Semiconductor MM74HC10N or equiv. 0615 162
U7 MOS dual retriggerable monostable multivibrator,16-pin DIP,National Semiconductor
MM74HC123N or equiv.
0615 282
U8 Microprocessor supervisor,8-pin DIP,Maxim MAX690EPA or equiv. 0635 27
U9 CHMOS microcontroller,16-bit/16-MHz,ROM-less,68-pin PLCC package, Intel N80C196KD or
equiv.
0615 459
U10 MOS quad 2-input NAND gate,14-pin DIP,Motorola MC74ACT00N or equiv. 0615 375
U11 MOS dual 2- to 4-line decoder,16-pin DIP,Motorola MC74ACT139N or equiv. 0615 378
U12,13 MOS octal latch,tri-state,20-pin DIP,Motorola MC74ACT573N or equiv. 0615 382
U14,15 MOS EPROM,32K x 8, 28-pin ceramic DIP, AMD AM27C256-70DI or equiv. 0615 401
U16,17 MOS octal buffer/driver,20-pin DIP,Motorola MC74ACT541N or equiv. 0615 381
U18,20 MOS octal D-type flip-flop,20-pin DIP,Motorola MC74ACT574N or equiv. 0615 383
U19 MOS octal tri-state D-type latch,20-pin DIP,Texas Instruments SN74HC573N or equiv. 0615 308
U21 MOS shift register,8-input,tri-state outputs,16-pin DIP,Motorola MC74HC595N or equiv. 0615 373
U22 Analog-to-digital converter,8-bit,8-pin plastic DIP,Texas Instruments TLC549IP or equiv. 0625 30
U23 Linear precision voltage reference,+5V,8-pin DIP,Maxim MAX675EPA or equiv. 0620 342
U24 Linear operational amplifier,low offset voltage,8-pin ceramic DIP, Precision Monolithics OP77EZ or
equiv.
0620 340
U25 MOS dual analog switch,SPST,14-pin ceramic DIP,Siliconix DG200ABK or equiv. 0605 14
U26 Linear operational amplifier,JFET input,8-pin DIP,Texas Instruments TL081IP or equiv. 0620 228
MISCELLANEOUS COMPONENTS
J1 Shorting bar,single,Molex 90059-0009 or equiv. 98306
Y1
Crystal,quartz,16.000 MHz 30297
