Table 21-2. Replaceable parts, RFL 93 Alarm I/O module – continued

Assembly No. 104775-6 and 104775-7

Circuit Symbol

(Figs. 21-3 & 21-4)

Description Part Number

SEMICONDUCTORS - continued

Q1-3 Transistor, NPN, 40V, 2N4401 42574

Q4 Transistor, silicon, NPN, 700V, 5A 102870

Q5, 6 Transistor, silicon, PNP, 2N3906 21565

U1 Integrated Circuit, MOS, tri-state buffer 0615 290

U2 Switch, solid state 102842

U3, 4 Opto device, iso-coupler, MOC8021 90271

MISCELLANEOUS COMPONENTS

J1-6 Connector, header, single, 2 ckt 32802 2

K4, 5 Relay, SPDT, 12V, PCB, sealed 101236

L1 Inductor, 10μH, 5%, 1.5A max 30285

L2-12 Inductor, 10μH, 5%, 1.5A max 102698

TB8, 9

Terminal block, 6 terminal 101233

RFL 9300 RFL Electronics Inc.

May 5, 2002 21 - 7 (973) 334-3100
