Table 27-2. Modbus Map - continued
Index Index
(Hex)
Description Units Format Write?
36 0023 Stub Bus (Inactive I=73 Ascii Active A:65 Ascii) - F20 No
37 0024 Comms Alm Dly
(DisableD=68 Ascii EnableE=69 Ascii)
- F20 No
38 0025 DC Offset Filter
(Disable D=68 Ascii Enable E=69 Ascii)
- F20 No
39 0026 Beeper (DisableD=68 Ascii EnableE=69 Ascii) - F20 No
40 0027 Transmit Addr 1 (value/1000) - F2 No
41 0028 Comms Mode (A=65 Ascii M=77 Ascii) - F20 No
42 0029 Active Channel 1or 2 - F1 No
43 002A Guard/Trip (D=68 Ascii I=73 Ascii) - F20 No
44 002B Resest Disp. Alrm (N=78 Ascii Y=89 Ascii) - F20 No
45 002C Alarm Trigger (E=69 Ascii D=68 Ascii) - F20 No
46 002D Single Pole (I=73 Ascii Ascii) - F20 No
47 002E Trip Release Code
(+100=1 +0=0 +CS=67 67=C Ascii)
- F17 No
48 002F System Label (only first character ) - F20 No
49 0030 Alarm Number (0 No Alarm) - F16 No
71 0046 Trip Counter - - No
72 0047 Fault Detector Counter - - No
1185 04A0 Slave Address F1 Yes
1351 0546 1 Trip Event? (1=Event Present) F1
1352 0547 Trip Code F22
1353 0548 Trip record time:Milliseconds in F10
1354 0549 six bytes from
1355 054A 01/01/1970 and Trip
1356 054B 2 Trip Event? (1=Event Present) F1
1357 054C Trip Code F22
1358 054D Trip record time:Milliseconds in F10
1359 054E six bytes from
1360 054F 01/01/1970 and Trip
1361 0550 3 Trip Event? (1=Event Present) F1
1362 0551 Trip Code F22
1363 0552 Trip record time:Milliseconds in F10
1364 0553 six bytes from
1365 0554 01/01/1970 and Trip
1366 0555 4 Trip Event? (1=Event Present) F1
1367 0556 Trip Code F22
1368 0557 Trip record time:Milliseconds in F10
1369 0558 six bytes from
1370 0559 01/01/1970 and Trip
1371 055A 5 Trip Event? (1=Event Present) F1
1372 055B Trip Code F22
1373 055C Trip record time:Milliseconds in F10
