Settings
Front-Panel Settings
The defaults for the pushbuttons and targets in the Front-Panel Settings category
are relay specific. See the product-specific instruction manual to find these
defaults.
Local Bit SELOGIC Table 12.32
SER Parameters Table 12.33
Table 12.28 Front-Panel Settings (Sheet 1 of 3)
Label Prompt
FP_TO Front Panel Display Time-Out (OFF,1–60 min)
EN_LEDC Enable LED Asserted Color (R,G)
TR_LEDC Trip LED Asserted Color (R,G)
PB1_LED Pushbutton LED 1 (SEL
OGIC Equation)
PB1_COL PB1_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB2_LED Pushbutton LED 2 (SELOGIC Equation)
PB2_COL PB2_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB3_LED Pushbutton LED 3 (SEL
OGIC Equation)
PB3_COL PB3_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB4_LED Pushbutton LED 4 (SEL
OGIC Equation)
PB4_COL PB4_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB5_LED Pushbutton LED 5 (SELOGIC Equation)
PB5_COL PB5_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB6_LED Pushbutton LED 6 (SEL
OGIC Equation)
PB6_COL PB6_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB7_LED Pushbutton LED 7 (SEL
OGIC Equation)
PB7_COL PB7_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB8_LED Pushbutton LED 8 (SELOGIC Equation)
PB8_COL PB8_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB9_LED
a
Pushbutton LED 9 (SELOGIC Equation)
PB9_COL
a
PB9_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB10LED
a
Pushbutton LED 10 (SELOGIC Equation)
PB10COL
a
PB10_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB11LED
a
Pushbutton LED 11 (SELOGIC Equation)
PB11COL
a
PB11_LED Assert and Deassert Color (Enter 2: R,G,A,O)
PB12LED
a
Pushbutton LED 12 (SELOGIC Equation)
PB12COL
a
PB_LED Assert and Deassert Color (Enter 2: R,G,A,O)
T1_LED Target LED 1 (SEL
OGIC Equation)
T1LEDL Target LED 1 Latch (Y, N)
T1LEDC T_LED Assert and Deassert Color (Enter 2: R,G,A,O)
T2_LED Target LED 2 (SEL
OGIC Equation)
T2LEDL Target LED 2 Latch (Y, N)
T2LEDC T_LED Assert and Deassert Color (Enter 2: R,G,A,O)
