12.15
Date Code 20171006 Instruction Manual SEL-400 Series Relays
Settings
DNP3 Settings—Custom Maps
DNP3 Settings—Custom Maps
The fault location minimum and maximum settings determine what fault data are
sent to a DNP3 master. This affects all DNP3 sessions using the current DNP3
map.
NOTE: MINDIST and MAXDIST only
apply to relays that provide a fault
location.
The remainder of this settings class consists of a set of freeform categories for
configuring the map for the various DNP3 data types. The category headers indi-
cate the syntax of the entries. Table 12.26 shows these headers. All entries require
a data label. The dead-band and scale-factor parameters are optional. The
defaults are relay specific, so refer to the product-specific instruction manual to
see the defaults for these settings.
Front-Panel Settings
Table 12.24 DNP3 Settings Categories
Settings Reference
DNP3 Fault Location Min and Max Table 12.25
Binary Input Map Table 12.26
Binary Output Map Table 12.26
Counter Map Table 12.26
Analog Input Map Table 12.26
Analog Output Map Table 12.26
Table 12.25 Minimum and Maximum Fault Location
Label Prompt Default Value
MINDIST Min Fault Location to Capture (OFF, –1000.0 to 1000.0) OFF
MAXDIST Max Fault Location to Capture (OFF, –1000.0 to 1000.0) OFF
Table 12.26 DNP3 Map Category Headers
Binary Input Map (Binary Input Label)
Binary Output Map (Binary Output Label)
Counter Map (Counter Label, Deadband)
Analog Input Map (Analog Input Label, Scale Factor, Deadband)
Analog Output Map (Analog Output Label)
Table 12.27 Front-Panel Settings Categories (Sheet 1 of 2)
Settings Reference
Front-Panel Settings Table 12.28
Selectable Screens for the Front Panel Table 12.29
Selectable Operator Pushbuttons Table 12.30
Front-Panel Event Display Table 12.31
Display Points
Local Control
