14.3
Date Code 20171006 Instruction Manual SEL-400 Series Relays
ASCII Command Reference
Command Description
within 30 seconds, the relay exits the 89OPEN command and reads the status of
the disconnect inputs. The state of Relay Word bits 89AMn and 89BMn deter-
mine which disconnect status message the relay displays (
Disconnect OPEN,
Disconnect CLOSED, or Status Undetermined - check wiring). Use Relay
Word bit 89OPENn as part of a SEL
OGIC Output control equation to open the
appropriate disconnect switch.
If the relay is disabled and you attempt an 89OPEN n command, the relay
responds with
Command Aborted because the relay is disabled. If the circuit
breaker control enable jumper J18C (BREAKER) is not in place, the relay aborts
the command and responds
Aborted: the breaker jumper is not installed.
When the 89OPEN n command is issued and the circuit breaker control enable
jumper is in place, the relay responds with
Open DISNAMn (Y/N)?. If you answer
Y <Enter>, the relay responds
Are you sure (Y/N)?. If you answer Y
<Enter>, the command is executed. If the response to either prompt is not y or Y,
the relay responds with
Command Aborted.
AACCESS
Use the AAC command to gain access to Access Level A (automation). See
Access Levels and Passwords on page 3.7 for more information.
ACCESS
Use the ACC command to gain access to Access Level 1 (monitor). See Access
Levels and Passwords on page 3.7 for more information.
BACCESS
Use the BAC command to gain access to Access Level B (breaker). See Access
Levels and Passwords on page 3.7 for more information.
Ta b l e 1 4. 3 89 O P EN
n
Command
Command Description Access Level
89OPEN n Set Relay Word bit 89OPENn B, P, A, O, 2
Ta b l e 1 4.4 AAC C o m m a n d
Command Description Access Level
AAC Go to Access Level A (automation). 1, B, P, A, O, 2
Table 14.5 ACC Command
Command Description Access Level
ACC Go to Access Level 1 (monitoring). 0, 1, B, P, A, O, 2
Ta b l e 1 4.6 BA C Co m m a n d
Command Description Access Level
BAC Go to Access Level B (breaker). 1, B, P, A, O, 2
