14.4
SEL-400 Series Relays Instruction Manual Date Code 20171006
ASCII Command Reference
Command Description
BNAME
The BNA command produces ASCII names of all relay Fast Meter status bits in a
Compressed ASCII format. See SEL Protocol on page 15.23 for more informa-
tion on Fast Meter and the Compressed ASCII command set.
BREAKER
NOTE: Not all SEL-400 series relays
support breaker monitoring.
Use the BREAKER command to display circuit breaker reports and the circuit
breaker history reports. You can also preload accumulated breaker monitor data.
The BRE command also resets the circuit breaker monitor data. To use the BRE
command, you must enable the circuit breaker monitors for the circuit breakers
of interest. See Circuit Breaker Monitor on page 8.1 for more information.
BRE
n
The BRE n command displays the comprehensive circuit breaker report that
includes interrupted currents, number of operations, and mechanical and electri-
cal operating times, among many parameters. The relay displays a listing of
breaker monitor alarms with the breaker report.
BRE
n
C and BRE
n
R
The BRE n C and BRE n R commands clear/reset the circuit breaker monitor
data. Options C and R are identical.
BRE C A and BRE R A
The BRE C A and BRE R A commands clear all circuit breaker monitor data for
all circuit breakers from memory. Options C A and R A are identical.
Ta b l e 1 4.7 B N A C o m m a n d
Command Description Access Level
BNA Display ASCII names of all relay status bits. 0, 1, B, P, A, O, 2
Ta b l e 1 4.8 B RE n Co m m a n d
Command Description Access Level
BRE n
a
a
Parameter
n
= breaker identification character.
Display the breaker report for the most recent Circuit
Breaker n operation.
1, B, P, A, O, 2
Ta b l e 1 4.9 B RE
n
C and BRE
n
R Commands
Command Description Access Level
BRE n
a
C
a
Parameter
n
= breaker identification character.
Clear Circuit Breaker n data to zero. B, P, A, O, 2
BRE n R Clear Circuit Breaker n data to zero. B, P, A, O, 2
