14.64
SEL-400 Series Relays Instruction Manual Date Code 20171006
ASCII Command Reference
Command Description
VIEW 1 Commands—Bit
Use commands in Table 14.145 to inspect a specific bit in the relay database. The
relay displays bit data as the bit label or number and the value logical 1 or logical
0. An example of a relay response for bit commands is
1:TARGET:ALTI = 0,
where
ALTI is the bit label and 0 is the bit value.
The command option bit is the bit number. If you access bit data, the relay dis-
plays the bit label or number and the value (logical 0 or logical 1). If you refer-
ence the data by label with the BL and bit_label options, the relay returns the
data according to the data type.
Use the VIEW 1 bit_label command as a shorthand method to inspect a specific
data bit in the relay database. The relay searches the entire relay database struc-
ture for the bit label you specified; this process takes more time and processing
than narrowing the search by using the VIEW 1 region command and the
VIEW 1 addr command with the bit label option bit_label.
Table 14.145 VIEW 1 Commands—Bit
a
a
Parameter
bit
is a number from 0–15, with 0 as the LSB (least significant bit).
Command Description Access Level
VIEW 1 addr bit Display the value at register address addr for the bit
number bit.
1, B, P, A, O, 2
VIEW 1 bit_label Display the value for the bit with the bit label bit_label. 1, B, P, A, O, 2
VIEW 1 region
bit_label
Display the value for the particular bit with the bit
label bit_label in the region region.
1, B, P, A, O, 2
VIEW 1 region
offset bit
b
b
Parameter
offset
is a decimal or hexadecimal number to indicate the offset.
Display the value for the bit bit in the region region
that is offset from the beginning of the region by offset
offset.
1, B, P, A, O, 2
