15.22
SEL-400 Series Relays Instruction Manual Date Code 20171006
Communications Interfaces
Software Protocol Selections
Synchrophasors Directory
Table 15.15 shows an example SYNCHROPHASORS directory. Synchrophasor
data recording is enabled when synchrophasors are enabled and EPMDR := Y.
The filename includes a time stamp based on the first data frame in the file. The
data in the file conforms to the C37.118 data format.
Software Protocol Selections
The relay supports the protocols and command sets shown in Table 15.16.
C4_10001.TXT 4-samples/cycle Compressed ASCII event report; read-only
C8_10001.TXT
a
8-samples/cycle Compressed ASCII event report; read-only
E4_10001.TXT 4-samples/cycle event report; read-only
E8_10001.TXT
b
8-samples/cycle event report; read-only
HR_10001.CFG Sample/second COMTRADE configuration file; read-only
HR_10001.DAT Sample/second COMTRADE binary data file; read-only
HR_10001.HDR Sample/second COMTRADE header file; read-only
a
In the SEL-487B, this is replaced with C1210001.TXT which provides a 12-samples/cycle Compressed
ASCII event report.
b
In the SEL-487B, this is replaced with E1210001.TXT which provides a 12-samples/cycle event report.
Table 15.14 EVENTS Directory Files (for Event 10001) (Sheet 2 of 2)
File Usage
Table 15.15 SYNCHROPHASORS Directory File Sample
File Description
080528,160910,0,ONA,1,ABC.PMU 080528 = date
160910 = time
0 = GMT (no time offset)
ONA = Last three letter (spaces removed) of the
PMSTN setting
1 = PMID setting
ABC = CONAM setting (company name)
PMU = file extension indicating synchrophasor
recording file
Table 15.16 Supported Serial Command Sets (Sheet 1 of 2)
PROTO Setting
Value
Command Set Description
SEL SEL ASCII Commands and responses
SEL SEL Compressed ASCII Commands and comma-delimited responses
SEL SEL Fast Meter Binary meter and digital element commands
and responses
SEL SEL Fast Operate Binary operation commands
SEL SEL Fast Message Fast Message database access, binary SER
commands and responses
MBA, MBB,
MBGA, or MBGB
SEL M
IRRORED BITS
communications
Binary high-speed control commands
NOTE: Not all SEL-400 series
relays support MBGA and MBGB
