15.42
SEL-400 Series Relays Instruction Manual Date Code 20171006
Communications Interfaces
Direct Networking Example
FTP Session
Figure 15.11 is a screen capture of an FTP session with the relay. The FTP client
used for this example is included with the Windows operating system and acces-
sible through a command prompt window. The operator connects to the relay,
moves to the SETTINGS directory, and collects the PORT 5 settings. Figure 15.11
shows a portion of the PORT 5 settings in the SET_P5.TXT file.
Table 15.31 SEL-421 PORT 5 Direct Networking Settings
Setting Name Setting Description
TIMEOUT 5 Port inactivity time-out in minutes (drops to Access
Level 0 on Telnet connections when this expires)
AUTO N Automessage disabled because engineering connection
will not require unsolicited messages from SEL-2030
FASTOP N Fast Operate messages disabled because they are not
required on engineering connection
TERTIM1 1 Length of time the channel must be idle before
checking for the termination string in seconds
TERSTRN \005 Transparent communications termination string
default of CTRL+E
TERTIM2 0 Length of time the channel must be idle before
accepting the termination string in seconds
IPADDR 10.201.0.112/16 IP network address
DEFRTR 10.201.0.1 Default router
ETCPKA N Disable TCP keep-alive functionality (IEC 61850 only)
KAIDLE 10 Length of time to wait with no detected activity
before sending a keep-alive packet (must be greater
than or equal to KAINTV)
KAINTV 1 Length of time to wait between sending keep-alive
packets after receiving no response for the prior keep-
alive packet (must be less than or equal to KAIDLE)
KACNT 6 Maximum number of keep-alive packets to send
NETPORT A Primary network port selected to Port A
FTIME 5 Fail over time-out—not used in this application
NETCSPD A Automatically detect network speed on Port C
NETDSPD A Automatically detect network speed on Port D—not
used in this application
FTPSERV Y FTP sessions enabled
FTPCBAN FTP SERVER: FTP connect banner
FTPIDLE 5 FTP connection time-out in minutes
FTPANMS N Anonymous login disabled so that passwords are
required for all FTP users
FTPAUSR “” Host user from which anonymous FTP client inherits
access rights—not used in this application
TCBAN HOST TERMINAL
SERVER:
Host Telnet connect banner
TPORT 23 Host Telnet TCP/IP port
TIDLE 5 Telnet connection time-out in minutes
