15.45
Date Code 20171006 Instruction Manual SEL-400 Series Relays
Communications Interfaces
Direct Networking Example
TERMINAL SERVER:
=ACC <Enter>
Password: ?OTTER <Enter>
Relay 1 Date: 02/04/2016 Time: 01:17:08.142
Station A Serial Number: 0000000000
Level 1
=>2AC <Enter>
Password: ?TAIL <Enter>
Relay 1 Date: 02/04/2016 Time: 01:17:23.082
Station A Serial Number: 0000000000
Level 2
=>>SHO P 5 <Enter>
Port 5
Protocol Selection
EPORT := Y MAXACC := C
SEL Protocol Settings
AUTO := Y FASTOP := N TERTIM1 := 1
TERSTRN := "\005"
TERTIM2 := 0
Fast Message Read Data Access
FMRENAB := Y FMRLCL := N FMRMTR := Y FMRDMND := Y
FMRTAR := Y FMRHIS := N FMRBRKR := N FMRSTAT := N
FMRANA := Y
IP Configuration
IPADDR := 10.201.0.112/16
DEFRTR := "10.201.0.1"
ETCPKA := Y KAIDLE := 10 KAINTV := 1 KACNT := 6
NETMODE := FIXED NETPORT := A NETASPD := AUTO NETBSPD := AUTO
NETCSPD := AUTO NETDSPD := AUTO
FTP Configuration
FTPSERV := N
HTTP Server Configuration
EHTTP := N
Telnet Configuration
ETELNET := Y
TCBAN := "TERMINAL SERVER:"
TPORT := 23 TIDLE := 15
DNP Configuration
EDNP := 0
Phasor Measurement Configuration
EPMIP := N
SNTP Protocol Selection
ESNTP := OFF
PTP Settings
EPTP := N
=>>QUI <Enter>
Figure 15.14 Example Telnet Session
