DNP3 Communication
DNP3 Documentation
0 232 Device attributes—Max. analog input index 1 0 129 0, 17
0 233 Device attributes—Number of analog inputs 1 0 129 0, 17
0 234 Device attributes—Support for double-bit events 1 0 129 0, 17
0 235 Device attributes—Max. double-bit binary index 1 0 129 0, 17
0 236 Device attributes—Number of double-bit binaries 1 0 129 0, 17
0 237 Device attributes—Support for binary input events 1 0 129 0, 17
0 238 Device attributes—Max. binary input index 1 0 129 0, 17
0 239 Device Attributes—Number of binary inputs 1 0 129 0, 17
0 240 Device attributes—Max. transmit fragment size 1 0 129 0, 17
0 241 Device attributes—Max. receive fragment size 1 0 129 0, 17
0 242 Device attributes—Device manufacturer’s software version 1 0 129 0, 17
0 243 Device attributes—Device manufacturer’s hardware version 1 0 129 0, 17
0 245 Device attributes—User-assigned location name 1 0 129 0, 17
0 246 Device attributes—User assigned ID code/number 1 0 129 0, 17
0 247 Device attributes—User-assigned device name 1 0 129 0, 17
0 248 Device attributes—Device serial number 1 0 129 0, 17
0 249 Device attributes—DNP3 subset and conformance 1 0 129 0, 17
0 250 Device attributes—Device manufacturer’s product name
and model
101290, 17
0 252 Device attributes—Device manufacturer’s name 1 0 129 0, 17
0 254 Device attributes—Non-specific all attributes request 1 0, 6 129 0, 17
0 255 Device attributes—List of attribute variations 1 0, 6 129 0, 17
1 0 Binary input—All variations 1 0, 1, 6, 7, 8,
17, 28
1 1 Binary input 1 0, 1, 6, 7, 8,
17, 28
129 0, 1, 17, 28
12
a
Binary input with status 1 0, 1, 6, 7, 8,
17, 28
129 0, 1, 17, 28
2 0 Binary input change—All variations 1 6, 7, 8
2 1 Binary input change without time 1 6, 7, 8 129 17, 28
2 2 Binary input change with time 1 6, 7, 8 129, 130 17, 28
2 3 Binary input change with relative time 1 6, 7, 8 129 17, 28
10 0 Binary output—All variations 1 0, 1, 6, 7, 8
10 1 Binary output
10 2
a
Binary output status 1 0, 1, 6, 7, 8 129 0, 1
12 0 Control block—All variations
12 1 Control relay output block 3, 4, 5, 6 17, 28 129 echo of
request
12 2 Pattern control block 3, 4, 5, 6 7 129 echo of
request
12 3 Pattern mask 3, 4, 5, 6 0, 1 129 echo of
request
Ta b l e 1 6 . 8 Relay D N P 3 Ob je ct List (Sheet 2 of 6)
Obj. Var. Description
Request
a
Response
a
Funct. Codes Qual. Codes Funct. Codes Qual. Codes
