16.14
SEL-400 Series Relays Instruction Manual Date Code 20171006
DNP3 Communication
DNP3 Documentation
20 0 Binary counter—All variations 1, 7, 8, 9, 10 0, 1, 6, 7, 8,
17, 28
20 1 32-Bit binary counter 1, 7, 8, 9, 10 0, 1, 6, 7, 8,
17, 28
20 2 16-Bit binary counter 1, 7, 8, 9, 10 0, 1, 6, 7, 8,
17, 28
20 3 32-Bit delta counter
20 4 16-Bit delta counter
20 5 32-Bit binary counter without flag 1, 7, 8, 9, 10 0, 1, 6, 7, 8,
17, 28
129 0, 1, 17, 28
20 6
a
16-Bit binary counter without flag 1, 7, 8, 9, 10 0, 1, 6, 7, 8,
17, 28
129 0, 1, 17, 28
20 7 32-Bit delta counter without flag
20 8 16-Bit delta counter without flag
21 0 Frozen counter—All variations
21 1 32-Bit frozen counter
21 2 16-Bit frozen counter
21 3 32-Bit frozen delta counter
21 4 16-Bit frozen delta counter
21 5 32-Bit frozen counter with time of freeze
21 6 16-Bit frozen counter with time of freeze
21 7 32-Bit frozen delta counter with time of freeze
21 8 16-Bit frozen delta counter with time of freeze
21 9 32-Bit frozen counter without flag
21 10 16-Bit frozen counter without flag
21 11 32-Bit frozen delta counter without flag
21 12 16-Bit frozen delta counter without flag
22 0 Counter change event—All variations 1 6, 7, 8
22 1 32-Bit counter change event without time 1 6, 7, 8 129 17, 28
22 2
a
16-Bit counter change event without time 1 6, 7, 8 129, 130 17, 28
22 3 32-Bit delta counter change event without time
22 4 16-Bit delta counter change event without time
22 5 32-Bit counter change event with time 1 6, 7, 8 129 17, 28
22 6 16-Bit counter change event with time 1 6, 7, 8 129 17, 28
22 7 32-Bit delta counter change event with time
22 8 16-Bit delta counter change event with time
23 0 Frozen counter event—All variations
23 1 32-Bit frozen counter event without time
23 2 16-Bit frozen counter event without time
23 3 32-Bit frozen delta counter event without time
23 4 16-Bit frozen delta counter event without time
Table 16.8 Relay DNP3 Object List (Sheet 3 of 6)
Obj. Var. Description
Request
a
Response
a
Funct. Codes Qual. Codes Funct. Codes Qual. Codes
