16.16
SEL-400 Series Relays Instruction Manual Date Code 20171006
DNP3 Communication
DNP3 Documentation
34 0 Analog input dead band—All variations 1 0, 1, 6, 7, 8,
17, 28
34 1 16-Bit analog input dead band 1, 2 0, 1, 6, 7, 8,
17, 28
129 0, 1, 17, 28
34 2
a
32-Bit analog input dead band 1, 2 0, 1, 6, 7, 8,
17, 28
129 0, 1, 17, 28
34 3 Single-precision floating point analog input dead band 1, 2 0, 1, 6, 7, 8,
17, 28
129 0, 1, 17, 28
40 0 Analog output status—All variations 1 0, 1, 6, 7, 8
40 1 32-Bit analog output status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 2
a
16-Bit analog output status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 3 Single-precision floating point analog output status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 4 Double-precision floating point analog output status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
41 0 Analog output block—All variations
41 1 32-Bit analog output block 3, 4, 5, 6 17, 28 129 echo of
request
41 2 16-Bit analog output block 3, 4, 5, 6 17, 28 129 echo of
request
41 3 Single-precision floating point analog output block 3, 4, 5, 6 17, 28 129 echo of
request
41 4 Double-precision floating point analog output block 3, 4, 5, 6 17, 28 129 echo of
request
50 0 Time and date—All variations
50 1 Time and date 1, 2 7, 8
index = 0
129 07,
quantity = 1
50 2 Time and date with interval
50 3 Time and date at last recorded time 2 7
quantity = 1
129
51 0 Time and date CTO—All variations
51 1 Time and date CTO 129 07,
quantity = 1
51 2 Unsynchronized time and date CTO 129 07,
quantity = 1
52 0 Time delay—All variations
52 1 Time delay, coarse
52 2 Time delay, fine 129 07,
quantity = 1
60 0 All classes of data 1, 20, 21, 22 6, 7, 8
60 1 Class 0 data 1, 22 6, 7, 8
60 2 Class 1 data 1, 20, 21, 22 6, 7, 8
60 3 Class 2 data 1, 20, 21, 22 6, 7, 8
60 4 Class 3 data 1, 20, 21, 22 6, 7, 8
70 1 File identifier
80 1 Internal indications 2 0, 1
index = 4, 7
Table 16.8 Relay DNP3 Object List (Sheet 5 of 6)
Obj. Var. Description
Request
a
Response
a
Funct. Codes Qual. Codes Funct. Codes Qual. Codes
