IEC 61850 Communication
Logical Nodes
RAGGIO8 Ra256.instMag.f RA256 Remote Analog Input 256
RAOGGIO1 Rao01.instMag.f RAO01 Remote Analog Output 01
RAOGGIO1 Rao02.instMag.f RAO02 Remote Analog Output 02
RAOGGIO1 Rao03.instMag.f RAO03 Remote Analog Output 03
•
•
•
RAOGGIO1 Rao30.instMag.f RAO30 Remote Analog Output 30
RAOGGIO1 Rao31.instMag.f RAO31 Remote Analog Output 31
RAOGGIO1 Rao32.instMag.f RAO32 Remote Analog Output 32
RAOGGIO2 Rao33.instMag.f RAO33 Remote Analog Output 33
RAOGGIO2 Rao34.instMag.f RAO34 Remote Analog Output 34
RAOGGIO2 Rao35.instMag.f RAO35 Remote Analog Output 35
•
•
•
RAOGGIO2 Rao62.instMag.f RAO62 Remote Analog Output 62
RAOGGIO2 Rao63.instMag.f RAO63 Remote Analog Output 63
RAOGGIO2 Rao64.instMag.f RAO64 Remote Analog Output 64
Functional Constraint = ST
a
ALTGGIO5 Ind01.stVal ALT01 Automation Latch 1
ALTGGIO5 Ind02.stVal ALT02 Automation Latch 2
ALTGGIO5 Ind03.stVal ALT03 Automation Latch 3
•
•
•
ALTGGIO5 Ind30.stVal ALT30 Automation Latch 30
ALTGGIO5 Ind31.stVal ALT31 Automation Latch 31
ALTGGIO5 Ind32.stVal ALT32 Automation Latch 32
ASVGGIO4 Ind001.stVal ASV001 Automation SEL
OGIC Var iabl e 1
ASVGGIO4 Ind002.stVal ASV002 Automation SEL
OGIC Var iabl e 2
ASVGGIO4 Ind003.stVal ASV003 Automation SEL
OGIC Var iabl e 3
•
•
•
ASVGGIO4 Ind126.stVal ASV126 Automation SEL
OGIC Var iabl e 126
ASVGGIO4 Ind127.stVal ASV127 Automation SEL
OGIC Var iabl e 127
ASVGGIO4 Ind128.stVal ASV128 Automation SEL
OGIC Var iabl e 128
ETHGGIO1 Ind01.stVal P5ASEL Port 5A active/inactive
ETHGGIO1 Ind02.stVal LINK5A Link status of Port 5A connection
ETHGGIO1 Ind03.stVal P5BSEL Port 5B active/inactive
ETHGGIO1 Ind04.stVal LINK5B Link status of Port 5B connection
ETHGGIO1 Ind05.stVal P5CSEL Port 5C active/inactive
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 4 of 11)
Logical Node Attribute
Data
Source
Comment
NOTE: Some relays support only 64
Automation SEL
OGIC Variables.
NOTE: Some relays do not support the
ETHGGIO1 Logical Node.
