17.37
Date Code 20171006 Instruction Manual SEL-400 Series Relays
IEC 61850 Communication
Logical Nodes
ETHGGIO1 Ind06.stVal LINK5C Link status of Port 5C connection
ETHGGIO1 Ind07.stVal P5DSEL Port 5D active/inactive
ETHGGIO1 Ind08.stVal LINK5D Link status of Port 5D connection
ETHGGIO1 Ind09.stVal LNKFAIL Link status of the active port
IN1GGIO14
b
Ind01.stVal IN101 Main Board Input 1
IN1GGIO14
b
Ind02.stVal IN102 Main Board Input 2
IN1GGIO14
b
Ind03.stVal IN103 Main Board Input 3
IN1GGIO14
b
Ind04.stVal IN104 Main Board Input 4
IN1GGIO14
b
Ind05.stVal IN105 Main Board Input 5
IN1GGIO14
b
Ind06.stVal IN106 Main Board Input 6
IN1GGIO14
b
Ind07.stVal IN107 Main Board Input 7
IN2GGIO15 Ind01.stVal IN201 First Optional I/O Board Input 1 (if installed)
IN2GGIO15 Ind02.stVal IN202 First Optional I/O Board Input 2 (if installed)
IN2GGIO15 Ind03.stVal IN203 First Optional I/O Board Input 3 (if installed)
•
•
•
IN2GGIO15 Ind22.stVal IN222 First Optional I/O Board Input 22 (if
installed)
IN2GGIO15 Ind23.stVal IN223 First Optional I/O Board Input 23 (if
installed)
IN2GGIO15 Ind24.stVal IN224 First Optional I/O Board Input 24 (if
installed)
IN3GGIO16 Ind01.stVal IN301 Second Optional I/O Board Input 1 (if
installed)
IN3GGIO16 Ind02.stVal IN302 Second Optional I/O Board Input 2 (if
installed)
IN3GGIO16 Ind03.stVal IN303 Second Optional I/O Board Input 3 (if
installed)
•
•
•
IN3GGIO16 Ind22.stVal IN322 Second Optional I/O Board Input 22 (if
installed)
IN3GGIO16 Ind23.stVal IN323 Second Optional I/O Board Input 23 (if
installed)
IN3GGIO16 Ind24.stVal IN324 Second Optional I/O Board Input 24 (if
installed)
IN4GGIO18
c
Ind01.stVal IN401 Third Optional I/O Board Input 1 (if
installed)
IN4GGIO18
c
Ind02.stVal IN402 Third Optional I/O Board Input 2 (if
installed)
IN4GGIO18
c
Ind03.stVal IN403 Third Optional I/O Board Input 3 (if
installed)
•
•
•
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 5 of 11)
Logical Node Attribute
Data
Source
Comment
