Schweitzer Engineering Laboratories SEL-421-4 - Page 1388

17.38
SEL-400 Series Relays Instruction Manual Date Code 20171006
IEC 61850 Communication
Logical Nodes
IN4GGIO18
c
Ind22.stVal IN422 Third Optional I/O Board Input 22 (if
installed)
IN4GGIO18
c
Ind23.stVal IN423 Third Optional I/O Board Input 23 (if
installed)
IN4GGIO18
c
Ind24.stVal IN424 Third Optional I/O Board Input 24 (if
installed)
IN5GGIO13
d
Ind01.stVal IN501 Fourth Optional I/O Board Input 01 (if
installed)
IN5GGIO13
d
Ind02.stVal IN502 Fourth Optional I/O Board Input 02 (if
installed)
IN5GGIO13
d
Ind03.stVal IN503 Fourth Optional I/O Board Input 03 (if
installed)
•
•
•
IN5GGIO13
d
Ind22.stVal IN522 Fourth Optional I/O Board Input 22 (if
installed)
IN5GGIO13
d
Ind23.stVal IN523 Fourth Optional I/O Board Input 23 (if
installed)
IN5GGIO13
d
Ind24.stVal IN524 Fourth Optional I/O Board Input 24 (if
installed)
LBGGIO1 Ind01.stVal LB01 Local Bit 1
LBGGIO1 Ind02.stVal LB02 Local Bit 2
LBGGIO1 Ind03.stVal LB03 Local Bit 3
•
•
•
LBGGIO1 Ind30.stVal LB30 Local Bit 30
LBGGIO1 Ind31.stVal LB31 Local Bit 31
LBGGIO1 Ind32.stVal LB32 Local Bit 32
MBOKGGIO13 Ind01.stVal ROKA Normal M
IRRORED BITS communications
Channel A status while not in loopback
mode
MBOKGGIO13 Ind02.stVal RBADA Outage too long on M
IRRORED BITS com-
munications Channel A
MBOKGGIO13 Ind03.stVal CBADA Unavailability threshold exceeded for M
IR-
RORED BITS communications Channel A
MBOKGGIO13 Ind04.stVal LBOKA Normal M
IRRORED BITS communications
Channel A status while in loopback mode
MBOKGGIO13 Ind05.stVal ANOKA Analog transfer OK on M
IRRORED BITS
communications Channel A
MBOKGGIO13 Ind06.stVal DOKA Normal M
IRRORED BITS communications
Channel A status
MBOKGGIO13 Ind07.stVal ROKB Normal M
IRRORED BITS communications
Channel B status while not in loopback
mode
MBOKGGIO13 Ind08.stVal RBADB Outage too long on M
IRRORED BITS com-
munications Channel B
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 6 of 11)
Logical Node Attribute
Data
Source
Comment
NOTE: Some relays do not support the
LBGGIO1 Logical Node.
NOTE: Some relays do not support the
MBOKGGIO13 Logical Node.
