18.14
SEL-400 Series Relays Instruction Manual Date Code 20171006
Synchrophasors
Settings for Synchrophasors
Ethernet Port Settings
The settings found in Table 18.4 are used for configuring synchrophasor data
transmission over an Ethernet port.
Descriptions for some of the settings in Tab le 18.4 are as follows.
EPMIP
Setting this to Y enables synchrophasor data transmission over Ethernet port. Set-
ting this to N disables the synchrophasor data transmission over Ethernet port.
The EPMIP := Y settings choice can be made when Global setting EPMU := N.
This setting combination will result in the relay ignoring any incoming synchro-
phasor requests regardless of whether the Ethernet port settings are correct or not.
PMOTS[2]
Selects the PMU Output transport scheme for session 1 and 2, respectively.
➤ PMOTS[2] := TCP establishes a single, persistent TCP socket for
transmitting and receiving synchrophasor messages (both commands
and data), as illustrated in Figure 18.3.
Table 18.4 Ethernet Port 5 Settings for Synchrophasors
Setting Description Default
EPMIP Enable PMU Processing (Y, N) N
PMOTS1 PMU Output 1 Transport Scheme (OFF, TCP, UDP_S,
UDP_T, UDP_U)
OFF
PMODC1 PMU Output 1 Data Configuration (1–5) 1
PMOIPA1 PMU Output 1 Client IP (Remote) Address (www.xxx.yyy.zzz) 192.168.1.3
PMOTCP1 PMU Output 1TCP/IP (Local) Port Number (1–65534) 4712
PMOUDP1 PMU Output 1 UDP/IP Data (Remote) Port Number (1–65534) 4713
PMOTS2 PMU Output 2 Transport Scheme (OFF, TCP, UDP_S,
UDP_T, UDP_U)
OFF
PMODC2 PMU Output 2 Data Configuration (1–5) 1
PMOIPA2 PMU Output 2 Client IP (Remote) Address (www.xxx.yyy.zzz) 192.168.1.4
PMOTCP2 PMU Output 2 TCP/IP (Local) Port Number (1–65534) 4722
PMOUDP2 PMU Output 2 UDP/IP Data (Remote) Port Number (1–65534) 4714
Figure 18.3 TCP Connection
C37.118
- Synchrophasor Command Start Request
- Synchrophasor Command Stop Request
- Synchrophasor Command Configuration Request 1
- Synchrophasor Command Configuration Request 2
- Synchrophasor Command Header Frame Request
- Synchrophasor Command Extended Frame
C37.118
- Synchrophasor Measurement
- Synchrophasor Configuration Response 1
- Synchrophasor Configuration Response 2
- Synchrophasor Header Frame
TCP Socket
(Persistent)
SEL-400
