18.17
Date Code 20171006 Instruction Manual SEL-400 Series Relays
Synchrophasors
Settings for Synchrophasors
FNR
Selects the numeric representation of the two frequency values in the synchro-
phasor data stream. If MFRMT = FM, this setting is forced to F, a floating point value.
NUMANA
Selects the number of user-definable analog values to be included in the synchro-
phasor data stream.
➤ Setting NUMANA := 0 sends no user-definable analog values.
➤ Setting NUMANA := 1–16 sends the user-definable analog values, as
listed in Table 18.5.
The format of the user-defined analog data is always floating point, and each
value occupies four bytes. If MFRMT = FM, this setting is forced to 0 and the
relay does not send any user-definable analog values.
NUMDSW
Selects the number of user-definable digital status words to be included in the
synchrophasor data stream.
Setting NUMDSW := 0 sends no user-definable binary status words.
Setting NUMDSW := 1, 2, 3, or 4 sends the user-definable binary status words,
as listed in Tab le 18.6 . If MFRMT = FM, this is forced to 1.
Table 18.5 User-Defined Analog Values Selected by NUMANA Setting
NUMANA Setting Analog Quantities Sent
Tota l N umber of By tes
Used for Analog Values
0None 0
1PMV64 4
2 Above, plus PMV63 8
3 Above, plus PMV62 12
4 Above, plus PMV61 16
5 Above, plus PMV60 20
6 Above, plus PMV59 24
7 Above, plus PMV58 28
8 Above, plus PMV57 32
9 Above, plus PMV56 36
10 Above, plus PMV55 40
11 Above, plus PMV54 44
12 Above, plus PMV53 48
13 Above, plus PMV52 52
14 Above, plus PMV51 56
15 Above, plus PMV50 60
16 Above, plus PMV49 64
