Synchrophasors
View Synchrophasors by Using the MET PM Command
The MET PM command shows if there is a serial port configuration error. If any
of the SPCERp bits assert, then the command displays
Y. Otherwise, it displays N.
The MET PM command checks for assertion of the PMTEST bit to show
whether the PMU is in a test mode. If the bit is asserted then the command dis-
plays Y. Otherwise, it displays
N.
The MET PM time command can be used to direct the PMU to display the syn-
chrophasor for an exact specified time, in 24-hour format. For example, entering
the command MET PM 14:14:12 will result in a response similar to Figure 18.6
occurring just after 14:14:12, with the time stamp 14:14:12.000000.
If you are not connected to the PMU when the MET PM time command issues
its timed response, you can use the MET PM HIS command to view this
response. This permits you to issue MET PM time to multiple PMUs at a certain
point in time and then go back later to see the results from all the PMUs at that
point in time.
See MET PM on page 14.39 for complete command options, and error messages.
=>>MET PM <Enter>
Relay 1 Date: 04/20/2015 Time: 22:02:12.000
Station A Serial Number: 1152490016
Time Quality Maximum time synchronization error: 0.000 (ms) TSOK = 1
Serial Port Configuration Error: N PMU in TEST MODE = N
Synchrophasors
VV Phase Voltages Pos. Sequence Voltage
VA VB VC V1
MAG (kV) 127.266 126.972 127.148 127.128
ANG (DEG) 73.542 -46.400 -166.103 73.677
VZ Phase Voltages Pos. Sequence Voltage
VA VB VC V1
MAG (kV) 76.383 76.103 76.277 76.254
ANG (DEG) 73.623 -46.319 -166.175 73.707
IS Phase Currents IS Pos. Sequence Current
IA IB IC I1S
MAG (A) 221.707 221.851 221.661 221.740
ANG (DEG) 57.667 -62.223 177.875 57.767
T Phase Currents IT Pos. Sequence Current
IA IB IC I1T
MAG (A) 440.487 441.507 440.698 440.897
ANG (DEG) -122.055 118.057 -1.933 -121.983
I IU Phase Currents IU Pos. Sequence Current
IA IB IC I1U
I1U
MAG (A) 0.000 0.000 0.000 0.000
ANG (DEG) 0.000 0.000 0.000 0.000
IW Phase Currents IW Pos. Sequence Current
IA IB IC I1W
MAG (A) 0.000 0.000 0.000 0.000
ANG (DEG) 0.000 0.000 0.000 0.000
IX Phase Currents IX Pos. Sequence Current
IA IB IC I1X
MAG (A) 0.000 0.000 0.000 0.000
ANG (DEG) 0.000 0.000 0.000 0.000
IY Phase Currents IY Pos. Sequence Current
IA IB IC I1Y
MAG (A) 0.000 0.000 0.000 0.000
ANG (DEG) 0.000 0.000 0.000 0.000
Figure 18.6 Sample SEL-487E MET PM Command Response
