10.17
Date Code 20171021 Instruction Manual SEL-421 Relay
Communications Interfaces
DNP3 Communication
01, 02 4 STSET Settings change or relay restart
01, 02 5 SALARM Software alarm
01, 02 6 HALARM Hardware alarm
01, 02 7 BADPASS Invalid password attempt alarm
01, 02 8 UNRDEV New relay event available
01, 02 9 SPO One or two poles open
01, 02 10 3PO All three poles open
01, 02 11 BK1RS Circuit Breaker 1 in ready state
01, 02 12 BK2RS Circuit Breaker 2 in ready state
01, 02 13 BK1LO Circuit Breaker 1 in lockout state
01, 02 14 BK2LO Circuit Breaker 2 in lockout state
01, 02 15 52AA1 Circuit Breaker 1, Pole A status
01, 02 16 52AB1 Circuit Breaker 1, Pole B status
01, 02 17 52AC1 Circuit Breaker 1, Pole C status
01, 02 18 52AAL1 Circuit Breaker 1, Pole A alarm
01, 02 19 52BAL1 Circuit Breaker 1, Pole B alarm
01, 02 20 52CAL1 Circuit Breaker 1, Pole C alarm
01, 02 21 52AA2 Circuit Breaker 2, Pole A status
01, 02 22 52AB2 Circuit Breaker 2, Pole B status
01, 02 23 52AC2 Circuit Breaker 2, Pole C status
01, 02 24 52AAL2 Circuit Breaker 2, Pole A alarm
01, 02 25 52BAL2 Circuit Breaker 2, Pole B alarm
01, 02 26 52CAL2 Circuit Breaker 2, Pole C alarm
01, 02 27 TLED_1 Front-panel target LED 1
01, 02 28 TLED_2 Front-panel target LED 2
01, 02 29 TLED_3 Front-panel target LED 3
01, 02 30 TLED_4 Front-panel target LED 4
01, 02 31 TLED_5 Front-panel target LED 5
01, 02 32 TLED_6 Front-panel target LED 6
01, 02 33 TLED_7 Front-panel target LED 7
01, 02 34 TLED_8 Front-panel target LED 8
01, 02 35 TLED_9 Front-panel target LED 9
01, 02 36 TLED_10 Front-panel target LED 10
01, 02 37 TLED_11 Front-panel target LED 11
01, 02 38 TLED_12 Front-panel target LED 12
01, 02 39 TLED_13 Front-panel target LED 13
01, 02 40 TLED_14 Front-panel target LED 14
01, 02 41 TLED_15 Front-panel target LED 15
01, 02 42 TLED_16 Front-panel target LED 16
01, 02 43 LDATPFW Leading true power factor A-Phase Terminal W
01, 02 44 LDBTPFW Leading true power factor B-Phase Terminal W
Table 10.14 SEL-421 DNP3 Default Data Map (Sheet 2 of 7)
Object Default Index Label Description
