10.18
SEL-421 Relay Instruction Manual Date Code 20171021
Communications Interfaces
DNP3 Communication
01, 02 45 LDCTPFW Leading true power factor C-Phase Terminal W
01, 02 46 LD3TPFW Leading true power factor three-phase Terminal W
01, 02 47 IN101 Main board Input 1
01, 02 48 IN102 Main board Input 2
01, 02 49 IN103 Main board Input 3
01, 02 50 IN104 Main board Input 4
01, 02 51 IN105 Main board Input 5
01, 02 52 IN106 Main board Input 6
01, 02 53 IN107 Main board Input 7
01, 02 54 PSV01 Protection SEL
OGIC Vari able 1
01, 02 55 PSV02 Protection SEL
OGIC Vari able 2
01, 02 56 PSV03 Protection SEL
OGIC Vari able 3
01, 02 57 PSV04 Protection SEL
OGIC Vari able 4
01, 02 58 PSV05 Protection SEL
OGIC Vari able 5
01, 02 59 PSV06 Protection SEL
OGIC Vari able 6
01, 02 60 PSV07 Protection SEL
OGIC Vari able 7
01, 02 61 PSV08 Protection SEL
OGIC Vari able 8
01, 02 62 ASV001 Automation SEL
OGIC Va ri a b l e 1
01, 02 63 ASV002 Automation SEL
OGIC Va ri a b l e 2
01, 02 64 ASV003 Automation SEL
OGIC Va ri a b l e 3
01, 02 65 ASV004 Automation SEL
OGIC Va ri a b l e 4
01, 02 66 ASV005 Automation SEL
OGIC Va ri a b l e 5
01, 02 67 ASV006 Automation SEL
OGIC Va ri a b l e 6
01, 02 68 ASV007 Automation SEL
OGIC Va ri a b l e 7
01, 02 69 ASV008 Automation SEL
OGIC Va ri a b l e 8
01, 02 70 OUT101 Main board Output 1
01, 02 71 OUT102 Main board Output 2
01, 02 72 OUT103 Main board Output 3
01, 02 73 OUT104 Main board Output 4
01, 02 74 OUT105 Main board Output 5
01, 02 75 OUT106 Main board Output 6
01, 02 76 OUT107 Main board Output 7
Binary Outputs
10, 12 0–31 RB01–RB32 Remote bits RB01–RB32
10, 12 32 OC1 Pulse Open Circuit Breaker 1 command
10, 12 33 CC1 Pulse Close Circuit Breaker 1 command
10, 12 34 OC2 Pulse Open Circuit Breaker 2 command
10, 12 35 CC2 Pulse Close Circuit Breaker 2 command
10, 12 36 89OC01 Open Disconnect Switch Control 1
10, 12 37 89CC01 Close Disconnect Switch Control 1
10, 12 38 89OC02 Open Disconnect Switch Control 2
Table 10.14 SEL-421 DNP3 Default Data Map (Sheet 3 of 7)
Object Default Index Label Description
