Date Code 20171021 Instruction Manual SEL-421 Relay
Communications Interfaces
DNP3 Communication
10, 12 39 89CC02 Close Disconnect Switch Control 2
10, 12 40 89OC03 Open Disconnect Switch Control 3
10, 12 41 89CC03 Close Disconnect Switch Control 3
10, 12 42 89OC04 Open Disconnect Switch Control 4
10, 12 43 89CC04 Close Disconnect Switch Control 4
10, 12 44 89OC05 Open Disconnect Switch Control 5
10, 12 45 89CC05 Close Disconnect Switch Control 5
10, 12 46 89OC06 Open Disconnect Switch Control 6
10, 12 47 89CC06 Close Disconnect Switch Control 6
10, 12 48 89OC07 Open Disconnect Switch Control 7
10, 12 49 89CC07 Close Disconnect Switch Control 7
10, 12 50 89OC08 Open Disconnect Switch Control 8
10, 12 51 89CC08 Close Disconnect Switch Control 8
10, 12 52 89OC09 Open Disconnect Switch Control 9
10, 12 53 89CC09 Close Disconnect Switch Control 9
10, 12 54 89OC10 Open Disconnect Switch Control 10
10, 12 55 89CC10 Close Disconnect Switch Control 10
10, 12 56 RST_DEM Reset demands
10, 12 57 RST_PDM Reset demand peaks
10, 12 58 RST_ENE Reset energies
10, 12 59 RST_BK1 Reset Breaker 1 monitor data
10, 12 60 RST_BK2 Reset Breaker 2 monitor data
10, 12 61 RSTTRGT Reset front-panel targets
10, 12 62 RSTMML Reset min/max metering data for the line
10, 12 63 RSTDNPE Reset (clear) DNP3 event summary analog inputs
Binary Counters
20, 22 0 ACTGRP Active settings group
20, 22 1 BKR1OPA Number of breaker operations on Circuit Breaker 1 A-Phase
20, 22 2 BKR1OPB Number of breaker operations on Circuit Breaker 1 B-Phase
20, 22 3 BKR1OPC Number of breaker operations on Circuit Breaker 1 C-Phase
20, 22 4 BKR2OPA Number of breaker operations on Circuit Breaker 2 A-Phase
20, 22 5 BKR2OPB Number of breaker operations on Circuit Breaker 2 B-Phase
20, 22 6 BKR2OPC Number of breaker operations on Circuit Breaker 2 C-Phase
20, 22
a,
b
7 KWHAOUT Positive (export) A-Phase energy, kilowatt hours
20, 22
a, b
8 KWHBOUT Positive (export) B-Phase energy, kilowatt hours
20, 22
a,
b
9 KWHCOUT Positive (export) C-Phase energy, kilowatt hours
20, 22
a,
b
10 KWHAIN Negative (import) A-Phase energy, kilowatt hours
20, 22
a,
b
11 KWHBIN Negative (import) B-Phase energy, kilowatt hours
20, 22
a,
b
12 KWHCIN Negative (import) C-Phase energy, kilowatt hours
20, 22
a, b
13 3KWHOUT Positive (export) three-phase energy, kilowatt hours
20, 22
a, b
14 3KWHIN Negative (import) three-phase energy, kilowatt hours
Table 10.14 SEL-421 DNP3 Default Data Map (Sheet 4 of 7)
