Basic Relay Operations
Making Simple Settings Changes
Step 5. Change settings.
a. Highlight the
SPEED setting.
b. Press ENT.
(The relay possibly requires a password here; see Passwords on
page 3.10 and Section 4: Front-Panel Operations.)
The LCD displays the
SPEED selection submenu that has all the
possible choices for serial data speeds.
The highlighted selection in Figure 3.24(f) indicates the default
setting of
9600 (bps).
c. Use the Up Arrow and Down Arrow navigation pushbuttons to select
a different speed.
d. Once you have selected a data speed, press the ENT pushbutton.
NOTE: Once you have changed
communications parameters, you
must change the corresponding
parameters in your terminal
emulation program to communicate
with the relay via a communications
port.
Step 6. End the settings session.
a. The relay returns to the previous category settings list screen.
Press ESC to return to the categories screen where you see the
Save Settings item at the bottom of the screen.
b. Use the Up Arrow and Down Arrow pushbuttons to highlight
Save
Settings
and press ENT.
c. Highlight
YES, and then press ENT.
The relay validates the setting and returns to the
PORT screen, as
shown in Figure 3.24(c).
Step 7. Press ESC repeatedly to return to the
MAIN MENU.
