5.27
Date Code 20171006 Instruction Manual SEL-400 Series Relays
Control
QuickSet Bay Control Screens
The relay does not include any default bay mimic screens with three-position dis-
connects. Should your application require different bay mimic screens with three-
position disconnects, contact SEL.
QuickSet Bay Control Screens
QuickSet provides an easy and intuitive way to configure and set the bay control
function.
Select the Bay Control button from the tree to see the first interactive bay forms
in QuickSet, as shown in Figure 5.18.
Figure 5.17 Bay Control One-Line Diagram With Three-Position Disconnect
Closed In-Line
BAYNAME
ESCNAVIG
I:9999A
V:99999kV
P:99999MW
Q:99999MV
BUS 1
SW3
SW4
BK1
SW1 SW2
BUS 2
To Next Page
