The following data are determined and logged:
● Date/time
● Log name with path
● Measuring version
● Input values
● Correction target
● Setpoints, measured values and differences
Note
Logging active
The measurement results can only be entered into a log once the measurement has been fully
completed.
Procedure
1. You are in the "JOG" mode and have pressed the "Workpiece zero" soft‐
key.
The "Measurement log" softkey cannot be used.
2. Select the required measurement version and measured the workpiece
zero as usual.
The measured values are displayed once the measurement has been
completed.
2. Press the "Measurement log" softkey to save the measurement data as
log.
The "Measurement log" softkey becomes inactive again.
Setting up the machine
4.6 Measuring the workpiece zero
Turning
114 Operating Manual, 06/2019, A5E44903486B AB
