5. Enter the number of the starting hole and press "OK".

Program processing starts with the specified technology (only for Shop‐

Turn programs) at the specified starting hole, and continues to all ad‐

ditional positions of the current position pattern and all of the following

position patterns.

Note

If you have hidden certain positions, then only the displayed positions

count for the number of the starting hole.

Machining the workpiece

6.7 Starting machining at a specific point

Turning

172 Operating Manual, 06/2019, A5E44903486B AB
