Procedure

1. Press the "Details" softkey.

2. Press the "Zoom" softkey.

A magnifying glass in the shape of a rectangular frame appears.

3. Press the "Magnify +" or <+> softkey to enlarge the frame.

- OR -

Press the "Magnify -" or <-> softkey to reduce the frame.

- OR -

Press one of the cursor keys to move the frame up, down, left or right.

4. Press the "Accept" softkey to accept the section.
