appropriate zero offset for the main spindle - or where relevant for the counterspindle - from the

specified chuck dimensions.

Programmable frames

All frames and zero offsets are taken into account in the simulation.

Note

Manually swiveled axes

Note that swivel movement in simulation and during simultaneous recording is also displayed

when the axes are swiveled manually at the start.

Display of the traversing paths

The traversing paths of the tool are shown in color. Rapid traverse is red and the feedrate is

green.

Note

Displaying the tailstock

The tailstock is only visible with the option "ShopMill/ShopTurn".

Machine manufacturer

Please also refer to the machine manufacturer's specifications.

References

SINUMERIK Operate (IM9) / SINUMERIK 840D sl Commissioning Manual

Simulating machining

7.1 Overview

Turning

236 Operating Manual, 06/2019, A5E44903486B AB
