Parameter Description Unit
ZE3 Jaw dimension of the counterspindle with jaw type 2 - (only for spindle chuck data "yes" and
for a counterspindle that has been set up)
mm
XR3 Tailstock diameter - (only for spindle chuck data "complete" and tailstock that has been set
up)
mm
ZR3 Tailstock length - (only for spindle chuck data "complete" and tailstock that has been set up) mm
XA Outside diameter – (only for tube and cylinder) mm
XI Inside diameter (abs) or wall thickness (inc) – (only for tube) mm
N Number of edges – (only for polygon)
SW or L Width across flats or edge length – (only for polygon) mm
W Width of the blank - (only for centered cuboid) mm
L Length of the blank - (only for centered cuboid) mm
Creating a G code program
8.6 Blank input
Turning
Operating Manual, 06/2019, A5E44903486B AB 271
