7. Continue programming up to the point where you want to repeat the

program blocks.

8. Press the "Various" and "Repeat progr." softkeys.

9. Enter the names of the start and end markers and the number of times

the blocks are to be repeated.

10. Press the "Accept" softkey.

The marked program blocks are repeated.

Creating a ShopTurn program

9.10 Repeating program blocks

Turning

Operating Manual, 06/2019, A5E44903486B AB 309
