⇒ A menu tree with all of the available measuring variants of the measuring

cycle function "Measure workpiece" can be found in the following reference:

Programming Manual Measuring cycles / SINUMERIK 840D sl/828D

⇒ A menu tree with all of the available measuring variants of the measuring

cycle function "Measure tool" can be found in the following reference:

Programming Manual Measuring cycles / SINUMERIK 840D sl/828D

Creating a ShopTurn program

9.14 Selection of the cycles via softkey

Turning

318 Operating Manual, 06/2019, A5E44903486B AB
