Parameter Description Unit
Position
(only for Shop‐
Turn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
(only for Shop‐
Turn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Drilling depth
● Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value
programmed for Z1. The angle entered in the tool list is taken into account.
● Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value programmed
for Z1.
Note: If it is not possible to define an angle for the drill in the tool management, it will not
be possible to select tip or shank (always tip, 0 field)
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
Predrilling
● Yes
● No
ZA - (only for pre‐
drilling "yes")
Predrilling depth (abs) or predrilling depth in relation to the reference point (inc) mm
FA - (only for pre‐
drilling "yes")
Reduced predrilling feedrate as a percentage of the drilling feedrate %
Predrilling feedrate (ShopMill) mm/min or
mm/rev
Predrilling feedrate (G code) Distance/
min or dis‐
tance/rev
Through drilling
● Yes
Through drilling with feedrate FD
● No
ZD - (only for
through drilling
"yes")
Depth for feedrate reduction (abs) or depth for feedrate reduction in relation to Z1 (inc) mm
Programming technology functions (cycles)
10.1 Drilling
Turning
350 Operating Manual, 06/2019, A5E44903486B AB
