Parameter Description Unit
Machining posi‐
tion (only for G
code)
● Single position
Drill hole at programmed position
● Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
FR (only for G
code)
Feedrate during retraction *
FR (only for Shop‐
Turn)
Feedrate during retraction mm/min
mm/rev
Machining
surface
(only for Shop‐
Turn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for Shop‐
Turn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
(only for Shop‐
Turn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
DT
● Dwell time (at final drilling depth) in seconds
● Dwell time (at final drilling depth) in revolutions
s
rev
* Unit of feedrate as programmed before the cycle call
Programming technology functions (cycles)
10.1 Drilling
Turning
354 Operating Manual, 06/2019, A5E44903486B AB
