● Dwell times
● Depth in relation to drill shank of drill tip
Clamping the spindle
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Input simple
For simple machining operations, you have the option to reduce the wide variety of parameters
to the most important parameters using the "Input" selection field. In this "Input simple" mode,
the hidden parameters are allocated a fixed value that cannot be adjusted.
Machine manufacturer
Various defined values can be pre-assigned using setting data.
Please refer to the machine manufacturer's specifications.
If the workpiece programming requires it, you can display and change all of the parameters
using "Input complete".
Approach/retraction during chip breaking
1. The tool moves with G0 to safety clearance of the reference point.
2. The tool drills with the programmed spindle speed and feedrate F = F · FD1 [%] up to the first
infeed depth.
3. Dwell time at drilling depth DTB.
4. The tool is retracted by retraction distance V2 for chip breaking and drills up to the next
infeed depth with programmed feedrate F.
5. Step 4 is repeated until the final drilling depth Z1 is reached.
6. Dwell time at final drilling depth DT.
7. The tool retracts to the retraction plane at rapid traverse.
Approach/retraction during stock removal
1. The tool moves with G0 to safety clearance of the reference point.
2. The tool drills with the programmed spindle speed and feedrate F = F · FD1 [%] up to the first
infeed depth.
3. Dwell time at drilling depth DTB.
4. The tool retracts from the workpiece for the stock removal with rapid traverse to the safety
clearance.
5. Dwell time at starting point DTS.
Programming technology functions (cycles)
10.1 Drilling
Turning
358 Operating Manual, 06/2019, A5E44903486B AB
