Parameter Description Unit
Acceleration (only
for technology,
yes)
(only in mode "without compensating chuck")
● Empty: Behavior the same as it was before the cycle was called
● SOFT: Jerk-limited (soft) acceleration of the axes
● BRISK: Abrupt acceleration of the axes
● DRIVE: Reduced axis acceleration
Spindle (only for
technology,
yes)
(only in mode "without compensating chuck")
● Speed controlled: Spindle for MCALL: Speed-controlled mode
● Position controlled: Spindle for MCALL: Position-controlled operation
Parameters in the mode "Input simple" (only for G code program)
G code program parameters
Input
● simple
RP Retraction plane mm
Parameter Description
Compensating
chuck mode
● with compensating chuck
● Without compensating chuck
Machining
position
● Single position
Drill hole at programmed position.
● Position pattern
Position with MCALL
Z0 Reference point Z mm
Z1 End point of the thread (abs) or thread length (inc)
It is inserted into the workpiece until it reaches Z1.
mm
Machining - (with
compensating
chuck)
● With encoder
Tapping with spindle encoder
● without encoder
Tapping without spindle encoder; selection:
- Define "Pitch" parameter
Pitch - (only ma‐
chining without en‐
coder)
● User input
Pitch is obtained from the input
● Active feedrate
Pitch is obtained from the feedrate
Thread Direction of rotation of the thread
● Right-hand thread
● Left-hand thread
(only in mode "without compensating chuck")
Programming technology functions (cycles)
10.1 Drilling
Turning
Operating Manual, 06/2019, A5E44903486B AB 379
