Figure 10-2 Y axis is not centered above the cylinder

YZC plane

You program in YZC if the Y axis should also move during machining. A value can be specified

for each position.

In addition to the possibilities of ZC, the following is also possible, for example.

;

<<

Figure 10-3 Y axis is traversed (Y0, Y1)

Programming technology functions (cycles)

10.1 Drilling

Turning

Operating Manual, 06/2019, A5E44903486B AB 387

Default Chapter5
