Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can be
adjusted using setting data.
Parameter Description Value Can be set in SD
PL Machining plane Defined in MD
52005
Table Thread table selection Without
G Change in thread pitch per revolution – (only for P = mm/rev or
in/rev):
Without change in thread pitch
0
XS
RS
Segment height, crowned thread
Radius crowned thread
0 mm
0 mm
D0 Initial plunge depth for reworking the threads 0 mm
½ Halve first infeed depth Yes
VR Return distance 2 mm x
Multiple threads 1 thread No
α0 Starting angle offset 0°
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Parameter "Tapered thread" in the "Input complete" mode
G code program parameters ShopTurn program parameters
Input
● Complete
PL Machining plane T Tool name
D Cutting edge number
S / V Spindle speed or constant cutting
rate
rpm
m/min
Programming technology functions (cycles)
10.2 Rotate
Turning
424 Operating Manual, 06/2019, A5E44903486B AB
